HJ-WM-PC290, HJ-WM-PC290V, HJ-WM-PC290FG, HJ-WM-PC290FGV uses high-quality EPISTAR LED chips, the beam angle is available in 120°.
HJ-WM-PC290, HJ-WM-PC290V, HJ-WM-PC290FG, HJ-WM-PC290FGV detailed size.
| Model | HJ-WM-PC290 | |||
|---|---|---|---|---|
| Applicable Scene | Concrete pool | |||
| LED Chips Brand | EPISTAR | |||
| Beam Angle | 120° | |||
| Controllers | HJ-0040, HJ-0040W, HJ-0050, HJ-0050W, HJ-0010, HJ-0-10V, DMX512 | |||
White(WW/NW/PW) |
√ | |||
| Power | 18W | 25W | 35W | |
| Voltage | 12V,24V(AC,DC) |
12V,24V(AC,DC) |
12V,24V(AC,DC) |
|
| RGB | √ | √ | √ | |
| RGBW | √ | √ | √ | |
| Body Material | ABS+UV | |||
| Lens Material | PC | |||
| Dimensions | Ф290 x 30 mm | |||
| Waterproof Way | Resin filled | |||
| Waterproof Level | IP68 | |||
| Model | HJ-WM-PC290V | |||
|---|---|---|---|---|
| Applicable Scene | Vinyl Liner Pool | |||
| LED Chips Brand | EPISTAR | |||
| Beam Angle | 120° | |||
| Controllers | HJ-0040, HJ-0040W, HJ-0050, HJ-0050W, HJ-0010, HJ-0-10V, DMX512 | |||
White(WW/NW/PW) |
√ | |||
| Power | 18W | 25W | 35W | |
| Voltage | 12V,24V(AC,DC) |
12V,24V(AC,DC) |
12V,24V(AC,DC) |
|
| RGB | √ | √ | √ | |
| RGBW | √ | √ | √ | |
| Body Material | ABS+UV | |||
| Lens Material | PC | |||
| Dimensions | Ф290 x 30 mm | |||
| Waterproof Way | Resin filled | |||
| Waterproof Level | IP68 | |||
| Model | HJ-WM-PC290FG | |||
|---|---|---|---|---|
| Applicable Scene | Fiberglass Pool | |||
| LED Chips Brand | EPISTAR | |||
| Beam Angle | 120° | |||
| Controllers | HJ-0040, HJ-0040W, HJ-0050, HJ-0050W, HJ-0010, HJ-0-10V, DMX512 | |||
White(WW/NW/PW) |
√ | |||
| Power | 18W | 25W | 35W | |
| Voltage | 12V,24V(AC,DC) |
12V,24V(AC,DC) |
12V,24V(AC,DC) |
|
| RGB | √ | √ | √ | |
| RGBW | √ | √ | √ | |
| Body Material | ABS+UV | |||
| Lens Material | PC | |||
| Dimensions | Ф290 x 30 mm | |||
| Waterproof Way | Resin filled | |||
| Waterproof Level | IP68 | |||
| Model | HJ-WM-PC290FGV | |||
|---|---|---|---|---|
| Applicable Scene | Fiberglass Pool, Vinyl Liner Pool | |||
| LED Chips Brand | EPISTAR | |||
| Beam Angle | 120° | |||
| Controllers | HJ-0040, HJ-0040W, HJ-0050, HJ-0050W, HJ-0010, HJ-0-10V, DMX512 | |||
White(WW/NW/PW) |
√ | |||
| Power | 18W | 25W | 35W | |
| Voltage | 12V,24V(AC,DC) |
12V,24V(AC,DC) |
12V,24V(AC,DC) |
|
| RGB | √ | √ | √ | |
| RGBW | √ | √ | √ | |
| Body Material | ABS+UV | |||
| Lens Material | PC | |||
| Dimensions | Ф290 x 30 mm | |||
| Waterproof Way | Resin filled | |||
| Waterproof Level | IP68 | |||
Surface mounted light in concrete pool one
Surface mounted light in concrete pool two
Wall-mounted light in vinyl liner pool
Wall-mounted light in vinyl liner & fiberglass pool
Wall-mounted light in fiberglass pool
